เครื่องตัดด้วยเส้นลวด (Wire EDM)

AccuteX AU-1000iA

CNC Wire EDM Machine AccuteX AU-1000iA | Year 2007 | Large-Scale

For sale: a professional, reliable, large-scale wire EDM machine from the renowned Taiwanese manufacturer AccuteX, model AU-1000iA. This machine is ideal for machining large and heavy parts, producing injection molds, dies, and tools with the highest precision.

Gbjdpfjzt Sinjx Al Dor
TECHNICAL SPECIFICATIONS:
- Manufacturer: AccuteX
- Model: AU-1000iA
- Year of manufacture: 2007
- CNC control: Proprietary AccuteX (Windows CE)
- Working travels (X × Y × Z): 1100 × 650 × 400 mm
- Travels in cone axes (U × V): 150 × 150 mm
- Cone cutting angle: ±21° (for height H=100 mm)
- Maximum workpiece weight: up to 5000 kg (fixed table design, moving column)
- Supported wire diameters: 0.15 - 0.33 mm
- Machining type: Submerged

KEY FEATURES AND BENEFITS:
- T-Base construction: Extremely stable body made of Meehanite castings, damping vibrations and resistant to thermal and mechanical loads.
- Optical (glass) linear scale system guaranteeing repeatability and positioning accuracy at the micro scale.
- Original AccuteX Wire Alignment Device for wire centering/positioning (in a dedicated box with wiring).

INCLUDED WITH THE MACHINE – A RICH SET OF AUXILIARY EQUIPMENT:
- Professional set of EDM clamping elements: numerous clamps, clamping jaws, positioning screws, and pins.
- Precision strips and base beams for quick mounting of large parts and molds on the work table.
- Additional consumable accessories and wire guiding mechanism components.
