Arburg 320C 500-170

Arburg 320C 500-170
Year of construction: 2011

Injection unit:
Screw diameter: 35 mm
Injection weight: 105 g
Injection pressure: 1470 bar
Metering volume: 115 ccm

Clamping unit:
Clamping force: 50 t
Distance between tie bars: 320x320 mm
Size of the clamping platens: 446x446 mm
Ejector: hydraulic
Clamping unit: hydraulic

Control system: SELOGICA touchscreen

Additional equipment:
Operating hours: approx. 35,000 h in automatic mode
Control system with air valve
Core pull control
Hardened injection unit - bimetal
Proportional valve on the injection unit - precise injection
Original Demag mold crane: chain, electrically controlled, 2 lifting speeds

Lsdpfx Aoxqx Uxeaforu
Dimensions:
Weight: 2310 kg
Length/width/height: 3.41x1.47x1.99 m

Drive:
Pumps/motor: 11 kW
Heating output: 9.4 kW
Total output: 20.4 kW

All offered machines are started by our service technicians before sale.
It is possible to obtain a video of the technical tests of the selected machine or participate in live technical tests at our company in Łódź.

Price: On request
