Brandt Optimat KDN 330

Used Edge Banding Machine

Year of manufacture: 2003
Equipped with a gluing unit for hot-melt adhesive granules
Glue reservoir located below the glue roller
Glue application via roller (co-rotating and counter-rotating modes)
Features:
Automatic edge magazine (coil and strip material)
Ncedpfx Ajy Nxgnsppeu
Pressure zone with pneumatically driven main pressure roller and additional rollers for optimal bonding of the glue layer
Centrally adjustable top pressure
Central manual lubrication of the chain conveyor
Control panel at the machine infeed
Machining Units:
End trimming unit (saw units) for front and rear overhang
2 motors, each 0.18 kW
Swivel range: 0–15°
Flush trimming unit (top and bottom) with vertical and horizontal tracing
Swivel range: 0–15°
2 motors with interchangeable cutters (straight/radius)
Digital counters for fast and precise adjustments
Pneumatic two-point adjustment
Buffing unit for final finishing
Additional Equipment:
Extendable support table up to 350 mm
Integrated section control (contactless operation)
Settings via keyboard and LED display
Technical Data:
Workpiece thickness: 8–50 mm
Edge thickness: 0.4–3 mm
Feed speed: approx. 9 m/min
Connected load: 4.1 kW
Compressed air: 6 bar
Weight: approx. 750 kg
Machine length: 3,150 mm

Location: Bulgaria
