เครื่องพิมพ์หน้ากว้าง Ricoh 6 หัว

The digital printer provides the highest print quality thanks to the LED UV curing system and eight 6th generation Ricoh printheads with CMYK +2x WHITE + 2x VARNISH configuration.
The machine allows you to print at a speed of 30 m2/hour on items, i.e.:
-> ceramics;
-> PVC boards
-> corrugated cardboard or plastic.
The maximum printing width on an item is 2500 mm.
The plotter is equipped with RIP ONYX Software, Panasonic servomotor and TAIWAN HIWIN linear motor.

Specifications of the YC2500HR large format printer

- type of carrier: PVC, metal plates, glass, wooden boards, acrylic, ceramics, wallpaper, corrugated cardboard, plastic
Codomrqy Uspfx Aglorh
- RIP software: ONYX Software
- printheads: Ricoh 6th generation
- number of printheads: 8
- head configuration: CMYK + 2x WHITE + 2x VARNISH
- maximum printing width: 2500 mm
- printing resolution: 300*900 dpi, 600*600 dpi, 600*900 dpi, 600*1200 dpi
- printing speed: 30 m2/hour
- type of ink: UV ink
- curing system: LED UV
- saving format: TIFF, JPEG, Postscript, EPS, PDF
- X-axis drive: TAIWAN HIWIN linear motor
- servomotor: PANASONIC
- YC2500HR printer guide: JANPAN THK
- encoder: Metal Renishaw UK
- USB interface: 2.0/3.0
- input voltage: single phase: 220V ± 10% (50/60 Hz, AC)
