ศูนย์เครื่องจักรกล - แนวนอน

STARRAG HECKERT CWK 1250

x-travel 1850 mm
y-travel 1250 mm
z-travel 1525 mm
Control 16 i- M Fanuc
Bsdoxukqgjpfx Acvjlp
type of pallet-changer 2-fach
size of pallet 1250 x 1000 mm
tool change unit 80 fach
tool taper ISO 50
0 30 kW
max. workpiece weight 5000 kg
turning speeds 20- 6000 U/min
rotary table 360 x 1 °
feeds - automatic programming 0- 15000 mm/min
rapid traverse 30 m/min
total power requirement 60 KW
weight of the machine ca. 27 t
dimensions of the machine ca. 8,3 x 7,3 x 4 m
80 tool position ATC. We will supply 300 pieces SK50 holders along with the
machine. Measuring tracer Renishaw, Cooling trough spindle and filtering
arrangement, 50 bar, Chip conveyor and exhaust ventilation.
Machine has worked for 28.000 spindle hours.
Control: Fanuc 16i-M.
