Berg & Schmid X-tech 410

Heavy-duty, fully hydraulic CNC bandsaw machine
for automatic and economical cutting of solid and profile materials.

Key features:
- Cutting range: round 410 mm or flat 410 x 410 mm
- Modern 2-axis CNC control
- Bandsaw blade monitoring with automatic feed rate adjustment
- Inching function for the first cut, 15 mm min. remaining piece length
- Stepless, frequency-controlled saw drive
- Clamping pressure adjustment for thin-walled tubes and profiles
- Hydraulically driven chip conveyor
- Automatic double-sided bandsaw blade lifting device
Rjdozl Ulpopfx Ahfscf
- Hydraulic bandsaw blade tensioning
- Material feed via precision ball screw and linear guide

Drive power: 5.5 kW
Working height: 730 mm
Paint finish: plating gray RAL 7036 and turquoise RAL 5018
Includes 1 bi-metal bandsaw blade 6150 x 41 x 1.3 mm
