เครื่องแกะสลักพล็อตเตอร์เลเซอร์ CO2

CORMAK LC1390ZD1

Ideal for engraving, marking, cutting from single to large series.

The working area of the Laser-1390ZD1 laser plotter is 1300x900 mm.

The price of the laser plotter includes: red dot, electrically lowered platform up to 300 mm, honeycomb overlay and scissor table, exhaust extraction: bottom with waste drawer, integrated commissionable compressor, fan, cooling.

The highlight of the engraving machine is the "through table", which allows materials of any length, 1300 mm wide and 100 mm high, or any width and 900 mm long, to be processed.

Dual cutting and engraving platforms: Scissor table and honeycomb table included.

Suitable for processing: Wood, organic glass, plastic, textiles, clothing, paper, leather, rubber, plastic and other non-metallic materials.

MACHINE DIMENSIONS 1940 x 1500 x 1030 mm
LASER TYPE CO2
MAXIMUM LASER POWER 160W (option: 80W, 100W, 130W, 180W)
EQUIPMENT WEIGHT 400 kg
MAXIMUM WORKING AREA 1300 x any / any x 900 mm
POSITIONING ACCURACY ± 0,01 mm
MECHANICAL RESOLUTION 0,0254 mm
MAXIMUM POWER CONSUMPTION 1000W
OPERATING TEMPERATURE 15 – 45 ℃
OPERATING SYSTEM Windows 95, 98, 2000, XP, Vista, 7, 8, 10 (32/64 bit)
Input file formats PLT, AI, DST, DXF, BMP
Compatible software CorelDraw AutoCAD Photoshop
Drive type stepper motors
Communication USB
Cjdpfxev Aatqe Aglorh
Tube cooling radiator CW5200
Material cooling air
