DOOSAN DNM 5700

DOOSAN dnm 5700

This 4-axis DOOSAN DNM 5700 was manufactured in 2021. It features an impressive X-axis travel of 1,050 mm, Y-axis travel of 570 mm, and Z-axis travel of 510 mm. The machine is equipped with a 30-position tool magazine and a spindle speed of 12,000 rpm. If you are looking to get high-quality machining capabilities, consider the DOOSAN DNM 5700 vertical machining centre we have for sale. Contact us for further details.

• Condition: Excellent (used)
• Functionality: Fully functional
• 15" display
• 2 MB part program storage / 1,000 programs
• Rapid traverse X-axis: 36 m/min
• Rapid traverse Y-axis: 36 m/min
• Rapid traverse Z-axis: 30 m/min
• Spindle torque: 118 Nm
• Through-spindle coolant: 12 bar
• Ethernet connection
• Ball screw nut cooling
• Tool breakage detection in magazine
• Automatic doors
• Standard-height column
• Hydraulic system 3A + 1B
• Seat air check
• Coolant level sensor

Additional equipment
Crodez I Tkgjpfx Ah Djh

• Robot interface
• 4th axis
• Hiwin RCV 250 rotary table
• HIWIN RTS 250 support
• 4th-axis fixture support hydraulic
• LNS MH500 chip conveyor
• Oil skimmer, belt type
• Coolant gun
• Mist collector interface

Technical Specification
Taper Size BT 40
