ศูนย์เครื่องจักรกลซีเอ็นซี - คอลัมน์เคลื่อนที่

HEDELIUS C60 - 2000

Ref. -No.: 10473
Manufacturer: HEDELIUS
Type: C60 - 2000
Year of construction: 2007
Type of control: CNC
Control: Heidenhain iTNC 530
Storage location: Halberstadt
Country of origin: Germany
X-Travel: 2000 mm
Y-Travel: 620 mm
Knsdpfx Aexqd Dlehusc
Z-Travel: 520 mm
Table Height: 860 mm
Max. Workpiece Weight: 2000 kg
Max. Tool Length: 330 mm
Max. Tool Diameter: 80/125 mm
Clamping Area: 2500 x 600 mm
T - groove width: 18 mm
T - slot spacing: 100 mm
Numbers Of Tools In Magazin: 30
Turning Speed Range - Stepless: 30 - 8000 RPM
Max. Torque: 198 Nm
Rapid Travel X/Y/Z: 45000 mm / min
Number of radial T-slots: 5
Machine length: 5400 mm
Machine width: 3300 mm
Machine Height: 3000 mm
Weight Of The Machine Ca.: 10,5 t

Further information:
Distance spindle nose - table: 100 - 620 mm
Tool clamping: disk spring

Machine can be inspected under power by arrangement.
