เครื่องไสไม้สี่ด้าน Leadermac HYPERMAC 930 2021

Leadermac HYPERMAC 930

Empty weight: 12.000 kg
Dimensions (LxBxH): 710 x 220 x 190 cm
Price: On request


- Year: 2021
- Documentation available: Yes


- └ Type Documentation: User manual, Operating system, Technical data, Electrical diagrams


- CE marking present: Yes
- CE certificate present: Yes
- Serial number: 2010016
- Number of spindles [pcs.]: 9


- └ Spindle 1:


- - Spindle type: Bottom
- - Motor power [kW]: 11
- - Spindle diameter [mm]: 50
- - Cutterhead speed [rpm]: 6000
- - Tool present: Yes


- └ Spindle 2:


- - Spindle type: Right
- - Motor power [kW]: 11
- - Spindle diameter [mm]: 50
- - Cutterhead speed [rpm]: 6000
- - Tool present: Yes


- └ Spindle 3:


- - Spindle type: Left
- - Motor power [kW]: 11
- - Spindle diameter [mm]: 50
- - Cutterhead speed [rpm]: 6000
- - Tool present: Yes


- └ Spindle 4:


- - Spindle type: Top
- - Motor power [kW]: 15
- - Spindle diameter [mm]: 50
- - Cutterhead speed [rpm]: 6000
- - Tool present: Yes


- └ Spindle 5:


- - Spindle type: Right
- - Motor power [kW]: 11
- - Spindle diameter [mm]: 50
- - Cutterhead speed [rpm]: 6000
- - Tool present: Yes


- └ Spindle 6:


- - Spindle type: Left
- - Motor power [kW]: 11
- - Spindle diameter [mm]: 50
- - Cutterhead speed [rpm]: 6000
- - Tool present: Yes


- └ Spindle 7:


- - Spindle type: Top
- - Motor power [kW]: 11
- - Spindle diameter [mm]: 50
- - Cutterhead speed [rpm]: 6000


- └ Spindle 8:


- - Spindle type: Bottom
- - Motor power [kW]: 15
- - Spindle diameter [mm]: 50
- - Cutterhead speed [rpm]: 6000
- - Tool present: Yes


- └ Spindle 9:


- - Spindle type: Universal
- - Motor power [kW]: 11
- - Spindle diameter [mm]: 50
- - Cutterhead speed [rpm]: 6000
- - Tool present: Yes




- Min. planing width [mm]: 20
- Max. planing width [mm]: 300
- Min. planing height [mm]: 10
- Max. planing height [mm]: 200
- Feed speed: Automatic


- └ Min. feed speed [m/min]: 6
- └ Max. feed speed [m/min]: 36


- Transport dimensions: 7100mm x 2200mm x 1900mm (l x w x h)
- Transport weight [kg]: 12000kg
Itodexiw Hqspfx Adxsr
- Transport packages [pcs.]: 1
