ศูนย์กลึงและกัด CNC

MORI SEIKI NZ 1500 T3Y3

turning diameter max. 320 mm
turning length 810 mm
control MSX 701 MAPPS III
standard turning dia. 200 mm
Njdpfx Aetqmqweh Sewc
Main spindle:
Number of revolutions max. 6.000 min/-1
power capacity - main spindel 22 / 18,5 kW
Bar feed max. 52 mm
spindle bore 61 mm
C-Axis 0,001 °
Subspindel:
Number of revolutions max. 6.000 min/-1
power capacity - Sub spindle 22 / 18,5 kW
Bar feed max. 52 mm
spindle bore 61 mm
C-Axis 0,001 °
Turret 1 + 3:
number of toolpositions je 16 pos.
Number of driven toolspositions je 16 pos.
Spindle speed - driven tools max. 6.000 min -1
power capacity - driven tools 7,5 / 5,5 kW
Y - Axis 110 (+65 / -45) mm
Turret 2:
number of toolpositions 16 pos.
Number of driven toolspositions 16 pos.
Spindle speed - driven tools max. 6.000 min -1
power capacity - driven tools 7,5 / 5,5 kW
Y - Axis 110 (+45 / -65) mm
axis stroke:
x-travel 1-3: 210 mm
y-travel 1-3: 110 mm
z-travel 1+3: 300 / 2: 810 mm
total power requirement 90 kVA
weight of the machine ca. 9,3 t
dimensions of the machine ca. 4,5 x 3,0 x 2,5 m
CNC - Turning- and MillingCenter
MORI SEIKI - NZ 1500 T3Y3

- Main- and Subspindle
- 3 turrets, 2x upper / 1x below
- 3x Y-Axis
- 3x 16-pos. tool-drive

- incl. 28x collets
- incl. Hainbuch changing device
