เครื่องจักรผลิตสายเคเบิล

NOKIA-MAILLEFER

Basic information:

Control system: Siemens S7-300

Technical details:

Materials processed to date: LDPE, HDPE, thermoplastic flame retardant, PE (-LLD, -LD, -MD, -HD)
Intended use: For the production of fiber optic cables and the extrusion of full plastic inserts for steel cables. In addition, a third extruder is installed which can be positioned in front of the system to alternatively use this extruder to produce hoses on the system.

Technical condition:
Electrical system modernized in 2002
Screw diameter: 1 x 100 / 1 x 45 / 1 x 80 mm
Screw length: 24 D
Cable diameter max: 24 mm
Speed max: 100 m/min
Die head: present
Operating voltage: 380 V
Frequency: 50 Hz
Electrical cabinet: present
Diameter measuring device: present
Plasticizer: present
Unwinder: present
Winder: present
Caterpillar, belt, and disc take-offs: present
Extruder: present
Number of extruders: 3
Cooling trough: present
Dancer / accumulator: present
Run-out: present
Mixer: present

Consisting of:

ITAL SPA 2200 unwinder
Drum flange diameter max: 2200 mm
CAPnet PLH 800 dancer
ITAL CN 800 caterpillar take-off
CAPnet DFO 350 fiber optic run-out
CAPnet JSF 801 guide roller
CAPnet RRH 801 guide roller
SWISSCAB GPN 18 helical spinner
SETIC TRLB 400-1 belt run-out
SWISSCAB GPN 18 helical spinner
MAILLEFER Guipeur 1 spinner
MAILLEFER Guipeur 2 spinner
BOREL continuous oven
NOKIA-MAILLEFER NMB 100-24D extruder
NOKIA-MAILLEFER NMA 30-24D extruder
ZUMBACH ODAC 64XY diameter measuring device
ITAL cooling section
Dryer
ZUMBACH ODAC 64XY diameter measuring device
Dcjdezb N R Hopfx Al Rjh
ZUMBACH ODAC 63 Trio measuring device
ITAL CN 800 caterpillar take-off
MAILLEFER ACO 1100-300 accumulator
CAPnet CHA 20-40C caterpillar take-off
NOKIA-MAILLEFER BTU 6-206 winder
Drum flange diameter max: 2250 mm
Electrical cabinet
MAILLEFER MXC80-24D extruder
MAILLEFER MXC80-24D extruder
MAILLEFER MXC80-24D extruder
MAILLEFER MXC80-24D extruder

ADEX cooling section
Cooling section / vacuum bath
