เครื่องบดทรงกระบอก

TOS Hostivař BUB

Technical data
- grinding length [mm] - 1500
- grinding diameter [mm] - 400
- range of table speed [mm/min] - 0 - 10
- smallest table travel [mm] - 0,001
- taper in tailstock sleeve {Morse no.] - 5
- grinding wheel dimensions [mm] - 500x80x203
- power of grinding wheel drive motor [kW] - 11
- power of grinding wheel drive motor [kW] - 3,5
- overall dimensions [mm]: length - 6650
width - 2300 (without desktop)
height - 1800
Podpevga Ayofx Af Tjrd
- weight of machine tool [kG] - 6900
- central lubrication system;
- Mitsubishi control system;
- movement of the grinding wheel headstock - application of ball screw and servo motor;
- table travel - use of ball screw and servo motor;
- headstock of the workpiece - use of a new motor along with stepless speed control controlled from the operator panel;
- "electronic wheel" for precise raids in both servo X and Z axes, e.g., for set-up work;

We also make machines with Siemens 828D or 840Dsl control.
It is possible to make machines up to a grinding length of 2000 / 2500 / 3000 mm.
