WALDRICH KLEINKNECHT WS III C 6.00 X 5000 CNC

WALDRICH KLEINKNECHT WS III C 6.00 X 5000 CNC

This 4-axis WALDRICH KLEINKNECHT WS III C 6.00 X 5000 CNC was manufactured in 2017. It features a maximum grinding length of 5,000 mm and a roll diameter capacity of approximately 600 mm. The machine is equipped with a modern CNC control system and includes essential safety equipment. If you are looking to get high-quality grinding capabilities, consider the WALDRICH KLEINKNECHT WS III C 6.00 X 5000 CNC cylindrical grinding machine we have for sale. Contact us for further details.

Iasdpjzcniksfx Acdsu
- Control Voltage: AC 230 V 50 Hz, DC 24 V, AC 24 V- Network System: TN- Mains Voltage: 3 AC 400 V ±5%- Mains Frequency: 50 Hz ± 1%- Solenoid Valve Voltage: DC 24 V- Coupling Relay Voltage: DC 24 V- Control Voltage for Monitor and PCs: AC 230 V 50 Hz- Ambient Temperature: > 5 and < 35°C- Relative Humidity: < 85%- Altitude: < 1000 m above sea level- Noise Level (Machine): < 75 dB (A)- Max. Grinding Diameter (with Ø 915 mm grinding wheel): 1,100 mm- Min. Grinding Diameter (with new grinding wheel 915 mm): 0 mm- Min. Grinding Diameter (with abraded grinding wheel 580 mm): 300 mm- Max. Workpiece Weight (in steady rests, limited by headstock framework size): 6,500 kg- Max. Workpiece Length (retracted faceplate): 5,450 mm- Center Height: approx. 750 mm- Max. Clearance Width (retracted faceplate and tailstock quill): 5,450 mm- Barrel Length: 5,150 mm- Connected Load: approx. 200 kVA (Connection power listed as 123 kW)- Machine Length: approx. 11,500 mm[- Machine Width: approx. 2,700 mm- Machine Height: approx. 2,500 mm- Machine Weight: approx. 40,000 kg- Headstock Motor Power: 22 kW- Headstock Drive: V-belt- Headstock Torque: 208 Nm- Headstock Speeds: 1-100 min⁻¹- Tailstock Center Sleeve Taper: Metric 80- Tailstock Movement: Motorized- Tailstock Clamping: Spring clamping cylinder- Tailstock Quill Travel: 270 mm- Tailstock Quill Movement: Manual and motorized- Z-Axis (Longitudinal Axis) Max. Speed: 0-6,000 mm/min- Z-Axis Motor Type: Siemens 1FT7- Z-Axis Rated Torque: 28 Nm- Z-Axis Stall Torque: 50 Nm- Z-Axis Motor Speed: 3,000 min⁻¹- X-Axis (Infeed Axis) Speed: 0-1,000 mm/min- X-Axis Motor Type: Siemens 1FT7- X-Axis Rated Torque: 3.7 Nm- X-Axis Stall Torque: 6.0 Nm- X-Axis Motor Speed: 6,000 min⁻¹- X-Axis Travel: 900 mm- X-Axis Infeed Accuracy: 1.0 µm- U-Axis (Eccentric Spindle) Speed: 50 mm/min- U-Axis Motor Type: Siemens 1FT7- U-Axis Rated Torque: 2.0 Nm- U-Axis Stall Torque: 3.5 Nm- U-Axis Motor Speed: 6,000 min⁻¹- U-Axis Travel: 3.0 mm- U-Axis Max. Crown (Radius): 1.5 mm- U-Axis Infeed Accuracy: 0.1 µm- Grinding Spindle Motor Type: Siemens 1PH8165-1DD00-2FA1- Grinding Spindle Motor Power: 31 kW (Optional upgrade to 71 kW motor at 1000 min⁻¹ and 673 Nm supported)- Grinding Spindle Motor Speed: 1,350 min⁻¹- Grinding Spindle Speed: 80-2,000 min⁻¹- Grinding Spindle Motor Torque: 257 Nm- Max. Cutting Speed (with corundum wheels): 45 m/s- Max. Cutting Speed (with CBN wheels, min. diameter 700 mm): 65 m/s- Grinding Wheel Max. Diameter: 914 mm- Grinding Wheel Min. Diameter: 580 mm- Grinding Wheel Bore: 508 mm- Grinding Wheel Max.
