TECHNICAL DETAILS
_____
MODEL CNC HAP 30160
BUILDING YEAR 2007
CAPACITY 3050 x 160 TON
Nhn0ftaz
Motor 15 kw
Alimentation 400V – 50 Hz
Height 2700mm
Lenght 4200 mm
Width 2100 mm
Stroke 200mm
Max pressure 285 Bar
Capacity reservoir 150 lt
Mass without tools 9800 kg
Weight Sup. tools 40kg
Weight inf. tools 55kg
Descent time after stop 102 ms
Movement after the stop 8mm
Safety distance 263.2
Number of phases 3
