เครื่องบดพื้นผิว

GER RS-50/25

Technical details:

grinding length: 500 mm
grinding width: 250 mm
workpiece height: 250 mm
table surface area: 530 x 200 mm
magnetic plate size: L:460 x B:150 x H:87 mm
table speed: 2 - 32 m/min
table adjustment: Längsweg: 550 mm
table adjustment: Querweg: 300 mm
feed of spindle: 0,001 mm/Hub
grinding spindle speed: 3.000 U/min
dimensions of grinding wheel: max. Ø 250 x B:25; Bohung Ø 76 mm
total power requirement: 4,3 kW
weight of the machine ca.: 2,2 t
dimension machine xH: 2,3 x 1,8 x 2,2 m
dimensions of hydaulic: L: 500 x B: 480 x H: 680 mm
dimension coolant device LxWxH: 0,65 x 0,45 x 0,8 m

The machine is currently equipped with a grinding wheel Ø 240 x 22mm.
On the table there is a permanent magnet plate with 30 induction fields, operated by a hand lever.
Operation via swiveling control panel.
no dressing device

incl. oil collecting tank; grinding wheel holder and available documentation
