HAAS DS30Y

HAAS DS30Y

This 4-axis HAAS DS30Y horizontal turning machine was manufactured in 2023. It features a maximum part swing of 533 mm and a maximum cutting diameter of 349 mm. The machine is equipped with a robust turret that accommodates 12 tools and offers a maximum cutting length of 826 mm. If you are looking to get high-quality turning capabilities, consider the HAAS DS30Y machine we have for sale. Contact us for further details regarding this machine.

• Capacities (S.A.E / Metric)
• Chuck size: 10.0 in (254 mm)
• Max part swing: 21.0 in (533 mm)
• Max cutting diameter (with BMT65 turret): 13.75 in (349 mm)
• Max cutting length (varies with workholding): 32.5 in (826 mm)
• Bar capacity: 3.00 in (76 mm)
• Between centers: 32.5 in (826 mm)
• Feedrates (S.A.E / Metric)
• Rapids on X: 472 ipm (12.0 m/min)
• Rapids on Y: 472 ipm (12.0 m/min)
• Rapids on Z: 945 ipm (24.0 m/min)
• Axis Motors (S.A.E / Metric)
• Max thrust X: 4100 lbf (18,238 N)
• Max thrust Y: 2300 lbf (10,231 N)
• Max thrust Z: 5100 lbf (22,686 N)
• Main Spindle (S.A.E / Metric)
• Spindle nose: A2-6
• Drive system: Direct speed, belt drive
• Max torque: 275.0 ft-lbf @ 500 rpm (373.0 Nm @ 500 rpm)
• Draw tube bore: ø 3.0 in (76 mm)
• Spindle bore: ø 3.50 in (88.9 mm)
• Main Spindle C Axis (S.A.E / Metric)
• Max speed: 60 rpm
• Max rating: 5.0 hp (3.7 kW)
• Positioning (±): 0.01°
• Brake diameter: 13.9 in (353 mm)
• Brake holding torque: 250 ft-lbf (339 Nm)
• Control type: Interpolated motion and positioning
• Secondary Spindle (S.A.E / Metric)
• Chuck size: 8.3 in (210 mm)
• Spindle nose: A2-5
• Drive system: Direct speed, belt drive
• Max rating: 15.0 hp (11.2 kW)
• Max speed: 4000 rpm
• Max torque: 100.0 ft-lbf @ 870 rpm (135.6 Nm @ 870 rpm)
• Spindle bore ø (non-through): 0.81 in (20.7 mm)
• Secondary Spindle C Axis (S.A.E / Metric)
• Max rating: 5.0 hp (3.7 kW)
• Max speed: 60 rpm
• Positioning (±): 0.01°
• Brake diameter: 8.5 in (216 mm)
• Brake holding torque: 140 ft-lbf (190 Nm)
• Control type: Interpolated motion and positioning
• Secondary Spindle Positioning (M119) (S.A.E / Metric)
• Positioning (±): 0.02°
• Brake diameter: 8.5 in (216 mm)
• Control type: Positioning only
• Turret (S.A.E / Metric)
• Number of tools: 12 stations
• OD vs ID tools: Any combination (will vary with turret)
• Boring bar rear clearance (from back of turret): 4.00 in (102.0 mm)
• Live Tooling (S.A.E / Metric)
• Max speed: 4000 rpm
• Drive ratio: 1:1
• Tooling: BMT65
• General (S.A.E / Metric)
• Coolant capacity: 55 gal (208 L)
• Air Requirements (S.A.E / Metric)
Knsdpezhwx Defx Af Eea
• Air required: 4 scfm @ 100 psi (113 L/min @ 6.9 bar)
• Inline air hose: 3/8 in
• Coupler (air): 3/8 in
• Air pressure min: 80 psi (5.5 bar)
• Electrical Specification (S.A.E / Metric)
• Drive system: Direct speed, belt drive
• Spindle power: 30.0 hp (22.4 kW)
• Input AC voltage (3 phase) - Low: 220 VAC; Full load amps (Low): 70 A
• Input AC voltage (3 phase) - High*: 440 VAC; Full load amps (High*): 35 A
• Dimensions - Shipping (S.A.E / Metric)
• Domestic pallet: 171 in x 90 in x 98 in (434 cm x 229 cm x 249 cm)
• Export pallet: 171 in x 90 in x 98 in (434 cm x 229 cm x 249 cm)

Additional equipment

• Bar feeder

Technical Specification
Counter Spindle Yes
Driven Tools Yes
